Trudeep bass
The sOUND
The SOUND
The Trudeep Bass sound is rich, deep, and articulate. Key design elements combine to provide the sound palette of huge rigs, in the smallest possible form.
Trudeep 9pm — 9" woofer plus midrange
Trudeep 10pm — 10" woofer plus midrange
Trudeep 10x — 10" woofer
• Side-ported, long and cuved vents (patent pending). These cabs offer superb F3 and F6, without port "chuffing", or driver-damaging over-extensions. And your bandmates will feel you, because the side-ported vents expand low end to both sides, not just in front of the cab.
• At any playing volume you can actually hear (and feel) fundamentals. When you get a full spectrum of bass sound, with solid lows at all volumes, you won't need to play as loud. The net result is overall lower SPL while still getting satisfying depth and bottom end in the mix.
• High extension, specialized woofers. They deliver low frequencies with surprising authority, which is the heart of the matter. All of your fundamentals, to the 22nd fret, are reproduced by the woofer. But the sonic complexity extends past the fundamental and initial harmonics.
9pm and 10pm — Plus Midrange — models use woofers that are like subwoofers, and have limited ability to sound musical above a certain range. They sound very deep, but lack complexity. This is where the midrange comes in.
• Harmonic complexity and "touch" lies in the mids and upper mids. This is why our "plus midrange" cabs use a woofer plus midrange, to create a rich and balanced, amazingly naturalistic sound. High power pro-audio midranges pick up where these woofers leave off, for articulate sound. The custom crossovers make this into a singular, cohesive, and musical sound.
• 10x cabs use a specialized woofer that goes almost as low as the 10pm. But this woofer has a pleasing transition into mids. This makes is usable in a single-driver cab, delivering the impressive girth and depth of a Trudeep vented cab. It will not be super-articulate like a 10pm, but is that needed in your band situation? And as an extension cab in a stack with a 10pm, you will be able to deliver a physically impressive low end.
• There are no tweeters in Trudeep Bass cabs. Tweeters would not survive. Our PlusMIdrange cabs smoothly transition from the low fundamentals of the woofers. In the 10x cab, a specialized woofer reaches in a musical way into the mids, just not upper mids. Either way, no tweeters, less string noise, yet a complete and musical sound with impressive low end. The sound is not identical between cabs, but with very consistent feeling and overall sound.
• High end passive electronics used in the PlusMidrange cabs feature custom, asymmetrical crossovers deliver rich harmonic tonalities for consistent, smooth reproduction across the frequency range. Heavy guage inductors and high power audio capacitors are used. The drivers are matched in sensitivity, needing NO heat-generating resisters in the crossovers.
• Components are hand-wired, point-to-point, with iso-elastic mounts, sealed from buffeting transients. The crossover housing, like the vents, forms part of the stiffening of the total cab, needing no additional braces.
